EPDM Eco-Friendly Running Track Material - UV Resistant, Non-Toxic & High Elasticity, Child-Safe

Categories	Environmental EPDM Plastic Track Material
Brand	Paint Universe
Model	PU-001
Color	red, blue, green, yellow, white, etc
Update Time	May 1,2025

Contact Now

Favorites

Detail Information

Information

EPDM Eco-Friendly Running Track

EPDM surfaces are constructed using EPDM granules, which are composed of ethylene-propylene-diene monomer (EPDM), a terpolymer of ethylene, propylene, and non-conjugated diene. Commercial production of EPDM began in 1963. As a novel high-molecular synthetic material developed for flooring applications, EPDM flooring exhibits outstanding aging resistance, electrical insulation properties, and ozone resistance. When installed, it forms a seamless, integrated surface without joints.

Scope Of Application

lt is applicable to all kinds of schools at all levels of kindergartens, professional stadiums, track andfield runways, semicircle areas, auxiliary areas, national fitness paths, indoor gymnasium training runways, playground road pavement, indoor and outdoor runways, tennis, basketball, volleyball.badminton, handball and other venues, parks, residential areas and other activity venues.

Product Features

1. Breathable and permeable

2. Good elasticity

3. Good flatness

4. Good weather resistance

5. Strong wear resistance

6. Do not thresh

7. Diverse colors

8. Durable and sturdy

Layered Diagram

Environmentally friendly EPDM rubber granules

Material Advantages

EPDM granules are made of synthetic rubber and can be produced in various colors, demonstrating excellent resistance to UV radiation and general chemical reactions. Their superiority is particularly evident in patterned field construction.

1. Chemical Stability‌: The product exhibits high corrosion resistance and exceptional chemical stability, with outstanding resistance to ozone aging and thermal-oxidative aging.

2. Excellent Elasticity‌: It maintains remarkable elasticity even at low temperatures.

3. Strong Adhesion‌: Demonstrates superior bonding properties.

4. Vibrant Colors‌: The granules feature stable, colorfast hues with high UV resistance and weather durability.

5. Customizable Production‌: Can be tailored to meet user-specific requirements, including color, particle size, and rubber content, ensuring diverse customer needs are fulfilled.

Material Parameter

EPDM Eco-Friendly Running Track Material Parameter
Parameter Name	Parameter Value
Main Ingredients	Polyether Polyol,Isocyanate,EPDM
Density	1-1.5g/cm³
Polymer Content	20-30%
Shore A Hardness	≥45
Tensile Strength (Mpa)	≥0.5
Fracture Elongation Rate /%	≥40
Vertical Deformation /mm	1.0-3.0
Thickness	Average thickness 13mm, minimum not less than 10mm
Slope Requirements	Longitudinal slope ≤ 0.1%, transverse slope ≤ 1.0%
Evenness	The gap under a 2-meter straightedge shall not exceed 3mm.
Drainage Performance	Permeable Type
Heavy metals (lead, chromium, cadmium, mercury) /mg/kg	≤2
Flame Retardancy	I
TVOC Emissions mg/(㎡. h)	≤5.0
Weather Resistance	Aging box 500H, performance qualified
Nail Resistance	Not resistant to nail shoes
Anti Slip Value (BPN. 20 ℃)	90-110 (Dry Test)

Material List

EPDM Eco-Friendly Running Track Ingredient List 13mm EPDM Plastic Flooring
Name Of Proportioning Material	Model	Packaging Specifications	Net Weight
Single component adhesive (base)	LS-002	200L 570mm diameter x 890mm height	200kg/barrel
Available granules: colored granules (2-4mm), white EPDM granules (2-4mm), black granules (2-4mm)	LS-032	/	25kg/bag
Single component adhesive	LS-003	200L 570mm diameter x 890mm height	200kg/barrel
EPDM granules (1-3mm)	LS-026	/	25kg/bag
Eco-friendly Diluent	LS-010	20L or 200L 275mm base diameter * 285mm surface diameter * 362mm height or 570mm diameter x 890mm height	20KG/barrel or 200kg/barrel
Line marking paint	LS-011	5L	5.1kg/barrel
Lead time (within days)	1-7 days, usually within 24 hours
Sales Method	Sell all materials for the ingredient list
